ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
FRAME GROUP
- FRAME 27.5” x 400 / 440 / 480 mm
- FORK SUNTOUR XCE28, travel 100 mm
TRANSMISSION GROUP
- CHAINWHEEL SHIMANO TOURNEY
- B.B.PARTS SHIMANO
- PEDAL VP
- CHAIN KMC
DERAILLEUR GROUP
- GEARS 21 speed
- SHIMANO Tourney RD-TY500 / SL-M315
WHEEL GROUP
- RIMS X11 DOUBLE WALL
- HUBS SHIMANO CENTERLOCK
- TIRES KENDA
OTHERS
- BRAKES SHIMANO MT-200 hydraulic disc brakes
- H/BAR & STEM ZOOM OVERSIZED
- SADDLE DDK CROSSER
SIZE CHART
| Frame size | S | M | L |
| A | 400 | 440 | 480 |
| B | 541.8 | 550.2 | 567.5 |
| C | 74.0° | 74.0° | 74.0° |
| D | 70.0° | 70.0° | 70.0° |
| E | 130.0 | 130.0 | 145.0 |
| F | 436.0 | 436.0 | 436.0 |
| G | 1060.7 | 1075.7 | 1096.8 |
