F: 170MM | R: 170MM | W: 29/27.5
- Brand New Lightweight Frame machined & Handbuilt in Britain
- 5 year frame warranty with Limited Lifetime Crash Replacement
- New Aggressive Enduro Race geometry optimised for 170mm front & rear travel
- New Linkage Driven Progressive (LDP?) suspension kinematics.
- More neutral pivot location allowing less drivetrain/suspension interaction
- Low position Asymmetric pivot – neutral suspension feel & increased chainring clearance
- Asymmetrical swingarm with increased longitudinal stiffness
- New top tube accessory/Bottle cage mounts and bottle dimple in frame
- New stiffer lower profile 56mm zerostack Head tube
- Geometry for reduced offset fork
- New Improved dropout with UDH gear hanger
- Boost 148 rear hub spacing
- New Top tube accessory/Bottle cage mounts and bottle dimple in frame
- Internal cable/hose routing
- 30 x 8 bearing mount compatible shock
- 205 x 65 trunnion shock for reduced friction
- Adjustable BB height
Πλαίσιο: |
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: MX – 29/27.5. Rear wheel travel: 170. |
Swingarm: | Bolt Type Allen Key Head (Boost 148mm Hub) |
Ανάρτηση Πίσω: | Ohlins TTX2 Air 205×65 |
Ποτήρια Λαιμού: |
FPD 44mm / 56mm zerostack
|
Ανάρτηση Εμπρός: |
Ohlins RXF 38 M.2 Air 170mm 29
|
Χειριστήριο: | Shimano XT 12spd |
Κασσέτα: | Shimano XT 10-51T 12spd |
Οδηγός Αλυσίδας: | E13 Vario Compact Guide |
Μ.Τριβή: | E13 |
Ανάπτυξη: | Hope Black 32t |
Οπίσθιο Ντεραγιέ: | Shimano XT 12spd |
Αλυσίδα: | KMC 12spd |
Τροχοί: | Stans Flow Mk4 + Hope Pro 4 (Black) 29 + 27 |
Ελαστικά: | Maxxis Minion DHF 2.5 3c EXO+ 29 / DHR II 2.4 3c EXO+ 27.5 |
Φρένα: |
Shimano XT Trail 203/180
|
Λαιμος Σέλας: | SDG Tellis 150mm |
Κολάρο Σέλας: | Strange Bolted |
Λαιμός: |
Burgtec Enduro Black 42.5mm
|
Σέλα: | SDG Strange Bel Air III |
Τιμόνι: |
Burgtec RideWide Enduro 800mm
|
Χερούλια: |
Strange Grappler Lock-On
|
Monocoque/6061-T6 Custom Butted Aluminium tubing | ||||
Frame Size | S | M | L | XL |
Seat Tube Length | 16″ | 17″ | 18″ | 19″ |
A. Head Angle | 63° | 63° | 63° | 63° |
B. Seat Angle (Effective) | 76° | 76° | 76° | 76° |
D. Top Tube (effective) | 605 | 625 | 645 | 665 |
E. BB Height (from ground) | 335 | 335 | 335 | 335 |
BB height (from axles | -16.2 | -16.2 | -16.2 | -16.2 |
F. Chainstay | 448 | 448 | 448 | 448 |
G. Head Tube | 110 | 110 | 120 | 130 |
H. Wheel base | 1250 | 1270 | 1292 | 1314 |
J. Reach | 458 | 466 | 484 | 502 |
K. Stack | 636 | 636 | 646 | 654 |
O. Fork Offset | 44 | 44 | 44 | 44 |
T. Rear Travel | 170 | 170 | 170 | 170 |
Standover | 706 | 724 | 750 | 770 |
Unless otherwise indicated all measurements are in mm. Frame angles are measured static, without rider sag. Bottom bracket height measured from ground with 740mm Front and 700mm Rear mm Ø tyre. |
TECHNICAL INFO
FORK TRAVEL | |||||||||
|
|||||||||
Shock Length | 205 x 65 mm | ||||||||
Rear Hub | 12 x 148mm Boost | ||||||||
Fork Offset | 44 mm | ||||||||
Seatpost Ø | 30.9 mm | ||||||||
Seatclamp Ø | 34.9 mm | ||||||||
Front Derailleur | N/A | ||||||||
BB Shell | 73 mm ISCG05 | ||||||||
Tapered Headset | Upper: ZS49/28.6 Lower: ZS56/40 |
FRAME SIZE | ΥΨΟΣ ΑΝΑΒΑΤΗ |
|
|
Small | 153cm – 168cm |
Medium | 165cm – 175cm |
Large | 173cm – 185cm |
Extra Large | 180cm – 193cm |
